LN-9400-00.9
DynaFlow TM User Manual - Introduction
9
The output of the first Gun is then fed into the
Master Channel input of the second Gun. The
second Gun is setup as follows:
Gun 2 =
Master Channel =
Material = Output of Gun 1 (Resin + 2 nd
Component)
Flow Controller = Color Change Value
(CCV)
(see Notes 1, 2, and 3)
Flow Meter = Gear-Type
Slave Channel =
Material = 3 rd Component
Flow Controller = MVR, with appropriate
size needle
Flow Meter = Piston or Gear, depending on
min/max flow rates
(see Notes 4 and 5)
Operating Mode = Manual or Auto
(see Notes 1, 2, and 3)
NOTES:
1. If the output of Gun 2 supplies one or more
hand guns, then Gun 2 should be operated in
Manual mode using a CCV for the Master
Channel flow controller.
2. If the output of Gun 2 supplies a single appli-
cator, then an MVR should be used for the
Master Channel flow controller and Gun 2
should be operated in Auto mode.
3. If the output of Gun 2 supplies multiple appl-
icators other then hand guns, then Gun 2 should
be operated in Manual mode using a CCV for the
Master Channel flow controller. Additional Guns
should be configured for each applicator as shown
below to provide automatic flow control for each
applicator.
Gun 3 through 6 =
Master Channel =
Material = Output of Gun 2 (Resin + 2 nd +
3 rd Components)
Flow Controller = DR1
Flow Meter = Gear-Type
Operating Mode = Auto
NOTE
Refer to Addendum C for complete
information regarding the flow limitations of
the DynaFlow Channel cards.
