LN-9400-00.9
DynaFlow TM User Manual - Maintenance
62
MAINTENANCE
TROUBLESHOOTING
Error Codes
The following is a complete list of error codes.
Some of these codes may not apply depending
on the specific control system configuration.
The corrective actions listed in the table are
discussed in more detail later in this section and
also included in the "HELP" screens located on
the operator interface.
Example Error Code: XXXX
1st Digit:
2 = GUN Alert
4 = DISK Error
9 = CHANNEL Fault
A = GUN Fault
B = SYSTEM Alert or Fault
2nd and 3rd Digit:
No specific meaning
4th Digit:
- If a GUN error, the number
indicates which GUN (1-8)
- If a CHANNEL error, the num-
ber indicates which CHANNEL
(1-8)
Displayed Text Fault Cause Corrective Action
Pot-Life Timer Ex-
pired -
GUN #<>
Pot-Life Timer has expired for GUN
indicated.
Last digit indicates CHANNEL #.
Verify the following:
1. Correct value for Pot-Life time.
2. Correct value for Mixed Volume.
If the above values are correct, then
fluid must be flushed from the GUN
immediately.
Code
2021
2022
2023
2024
2025
2026
2027
2028
9011
9012
9013
9014
9015
9016
9017
9018
Out Of Tolerance -
CHANNEL #<>
The indicated CHANNEL is outside
it’s maximum tolerance limit as speci-
fied by the FLOW
TOLERANCE parameter.
Last digit indicates CHANNEL #.
Check the following:
1. Kp, Ki, and Kd gains set wrong which
may cause unstable fluid regulation.
2. Running the wrong JOB # which
may include the wrong Kp, Ki, and Kd
values.
2061
2062
2063
2064
2065
2066
2067
2068
Gun Not Ready -
GUN #<>
Indicated GUN # is not ready. This
means that the GUN # has been
given a RUN command without be-
ing enabled, or the GUN has faulted.
Last digit indicates CHANNEL #.
Verify that the GUN is enabled and not
faulted. Each GUN must have the Ext.
Fault/Enable Input active, or the Global
Gun Enable active.
ERROR CODES
