LN-9400-00.9
If a CVT or UPS is to be used on the
input to the Control Panel, use a CVT with
a Volt-Amp (VA) output rating equal to
or greater than the output voltage multi-
plied by the control panel fuse rating (see
specification section). Also make sure that
the device input ratings correspond with
the voltage and frequency of the source
supplied by the FUSED DISCONNECT.
The device output should be rated for 240
VAC maximum.
C A U T I O N
!
Before applying power to the control
panel, verify that it is set to match the
source voltage. There may sometimes be
a voltage selection switch (usually located
on the DC power supplies) to select be-
tween 120 VAC and 240 VAC or different
indicator bulbs may be required.
C A U T I O N
!
DynaFlow TM User Manual - Installation
19
Do not install or service this equip-
ment or perform installation or adjustment
procedures unless you are properly trained
and qualified.
Installing and servicing this equipment
requires access to parts which could cause
electric shock or serious injury if work is not
performed properly.
All work must comply with applicable local
and national regulations and codes.
W A R N I N G
!
INPUT POWER
Input supply voltage connections should be made
from a FUSED DISCONNECT that is located in
an accessible area near the Control Enclosure.
Electrical conduit is recommended for the input
power wiring. Use 3 cond. 14 ga. wire for incom-
ing AC power supply.
If using SO type portable cord, a strain relief rated
for the diameter of cord being used is required for
protection against cord abrasion and damage.
The protective ground conductor must be termi-
nated directly to the protective conductor ground
terminal located inside the Control Enclosure which
is marked with symbol -
If there are large AC line voltage fluctuations or
voltage transients such as those typically produced
by heavy electric machinery or welding equipment,
then a constant voltage transformer (CVT) or an
uninterruptedly power supply (UPS) should be
used between the FUSED DISCONNECT and
the Control Panel.
