Publication 1785-UM012D-EN-P - July 2005
C-14 Maximizing System Performance
Using Program Control
Instructions
Scan time can increase based on how you use JMP/LBL instructions and
FOR/NXT instructions.
Using JMP/LBL Instructions
Keep in mind these issues when programming JMP/LBL instructions:
Using FOR/NXT Instructions
The FOR/NXT instructions have the same impact on execution time as the
JMP instruction. The execution for a FOR/NXT loop depends on the
program file that contains the instructions.
The estimated execution time for a FOR/NXT loop is:
8.1 + (number_of_loops
∗
15.9) + (file_number
−
2)
∗
0.96
The greater the program file number, the longer it takes to complete the
FOR/NXT loops.
Instruction
Consideration
JMP
The execution time required for a JMP instruction depends on
the program file that contains the JMP instruction.
The estimated execution time for a JMP instruction is:
8.9 + (file_number
−
2)
∗
0.96
The greater the program file number, the longer it takes to
complete a scan of the JMP instruction.
LBL
Each LBL instruction uses 2 words of memory in the program file
plus additional memory, depending on the label number itself.
Each label number is placed in a label table. Each entry in the
label table uses 2 words of memory, starting from label 0. For
example, LBL 10 uses 22 (2 words
∗
11th entry) words of
memory in the label table.
If you later delete LBL 10, the label table does not deallocate
previously used space. The only way to recover this space is to
upload and then re-download the program.
