1
Publication 1785-UM012D-EN-P - July 2005
Chapter
11
Communicating with Devices on an Ethernet
Network
Using This Chapter
Media and Cabling
Ethernet is a local area network that provides communication between various
devices at 10 Mbps. The physical communication media you use can be any
standard 802.3 media, including:
•
thick-wire coaxial cable (10Base5)
•
thin-wire coaxial cable (10Base2)
•
twisted pair (10Base-T)
•
fiber optic
•
broadband
The Ethernet port (channel 2) connects to either a thin-wire, thick-wire, or
twisted-pair network via a 15-pin transceiver or Medium Access Unit (MAU)
connection. See Appendix G for detailed information about Ethernet cable
connections.
For Information About
Go to Page
Media and cabling
Assigning your IP address
Network addressing
Configuring channel 2 for Ethernet communication
Using advanced Ethernet functions
Using domain name service
Using the embedded web server
Using multihop messaging
Communicating with ControlLogix devices
Interpreting error codes
Interpreting Ethernet status data
Ethernet PLC-5 performance considerations
