B-6 Processor Status File
30
You tried to jump to one too many nested subroutine files
Non-recoverable
The fault routine will be executed
but cannot clear major fault bit 2.
31
You did not enter enough subroutine parameters
32
You jumped to an invalid (non-ladder) file
33
You entered a CAR routine file that is not 68000 code
34
You entered a negative preset or accumulated value in a timer instruction
Recoverable
35
You entered a negative time variable in a PID instruction
36
You entered an out-of-range setpoint in a PID instruction
37
You addressed an invalid module in a block-transfer, immediate input, or immediate output
instruction
38
You entered a RET instruction from a non-subroutine file
Non-recoverable
The fault routine will be executed
but cannot clear major fault bit 2.
39
FOR instruction with missing NXT
40
The control file is too small for the PID, BTR, BTW, or MSG instruction
Recoverable
41
NXT instruction with missing FOR
Non-recoverable
The fault routine will be executed
but cannot clear major fault bit 2.
42
You tried to jump to a non-existent label
43
File is not an SFC
44
Error using SFR. This error occurs if:
• you tried to reset into a simultaneous path
• you specified a step reference number that is not found or is not tied to a step (it is a transition)
• the previous SFR to a different step is not complete
45
Invalid channel number entered
Recoverable
46
Length operand of IDI or IDO instruction is greater than the maximum allowed
47
SFC action overlap. An action was still active when the step became re-activated
Non-recoverable. The fault
routine will be executed but
cannot clear major fault bit 2.
This
Fault
Code
Indicates this Fault
And the Fault Is
