Publication 1785-UM012D-EN-P - July 2005
Processor Status File B-3
S:3-10
This Word Stores
S:3 to S:6 Active Node table for channel 1A
WordBitsDH+ Station #
30-1500-17
40-1520-37
50-1540-57
60-1560-77
S:7 Global status bits: (See also S:27, S:32, S:33, S:34, and S:35)
• S:7/0-7 rack fault bits for racks 0-7
• S:7/8-15 unused
S:8 Last program scan (in ms)
S:9 Maximum program scan (in ms)
S:10Minor fault (word 1)
See also S:17
S:10/00 Battery is low (replace in 1-2 days)
S:10/01 DH+ active node table has changed
S:10/02 STI delay too short, interrupt program overlap
S:10/03 memory module transferred at power-up
S:10/04 Edits prevent SFC continuing; data table size changed during
program mode; reset automatically in run mode
S:10/05 Invalid I/O status file
S:10/06 reserved
S:10/07 No more command blocks exist to execute block-transfers
S:10/08 Not enough memory on the memory module to upload the program
from the controller
S:10/09 No MCP is configured to run
S:10/10 MCP not allowed
S:10/11 PII word number not in local rack
S:10/12 PII overlap
S:10/13 no command blocks exist to get PII
S:10/14 Arithmetic overflow
S:10/15 SFC “lingering” action overlap - step was still active when step
was reactivated
