Preparing Power-Up Routines 14-3
To set and reset bits:
1. Cursor to the bit location.
2. Set by entering 1; reset the bit by entering 0.
The above table describes the possible start-up routines. For more information
about fault routines, see chapter 16.
See chapter 21 for definitions of the user control bits (S:26/0-6).
Possible Controller Power-Up Routines
Use this Bit To
0
Control controllers that are using SFCs
This bit determines if the SFC restarts or resumes at the last active
step after a power loss.
1
Select power-loss protection
If this bit is set and a power loss occurs, the controller sets major
fault bit 5 and executes a fault routine you define before it returns to
normal program scan.
If You are
With
And You Want to:
Then Set Bit 0 and 1 as Shown:
15..............0
Using SFCs
No fault routine
Restart at the first step
xxxxxxxx xxxxxx00
Restart at the last active step
xxxxxxxx xxxxxx01
Not using SFCs
Fault routine
Start at the first file
xxxxxxxx xxxxxx0x
Restart using the fault routine file
xxxxxxxx xxxxxx1x
Using a fault file
SFCs
Restart using the fault file and then the first step
xxxxxxxx xxxxxx10
Restart using the fault file and then the last active step xxxxxxxx xxxxxx11
Not using a fault file
Not using SFCs
Start at the first file in the controller’s memory.
xxxxxxxx xxxxxx00
Each x indicates a bit that can be 0 or 1 for the status value described.
