Rockwell Automation 1785-Lxxx Enhanced and Ethernet PLC-5 Programmable Controllers User Manual
Page 271

Publication 1785-UM012D-EN-P - July 2005
System Specifications A-3
PLC-5/60
(1785-L60B)
64 K
(2)
3072 (any mix) or
3072 in + 3072 out
(complementary)
4 DH+/Remote I/O (Adapter or
Scanner)
1 serial port, configurable for
RS-232 and 423 and RS-422A
compatible
24 (0-27)
93
0
92
PLC-5/60L
(1785-L60L)
64 K
2
3072 (any mix) or
3072 in + 3072 out
(complementary)
2 DH+/Remote I/O (Adapter or
Scanner)
1 serial port, configurable for
RS-232 and 423 and RS-422A
compatible
1 Extended Local I/O
24 (0-27)
81
16
64
PLC-5/80
(1785-L80B)
PLC-5/86
(1785-L86B)
100 K
(3)
3072 (any mix) or
3072 in + 3072 out
(complementary)
4 DH+/Remote I/O (Adapter or
Scanner)
1 serial port, configurable for
RS-232 and 423 and RS-422A
compatible
24 (0-27)
93
0
92
PLC-5/80E
(1785-L80E)
100 K
3
3072 (any mix) or
3072 in + 3072 out
(complementary)
2 DH+/Remote I/O (Adapter or
Scanner)
1 serial port, configurable for
RS-232 and 423 and RS-422A
compatible
1 channel Ethernet only
24 (0-27)
65
0
64
1
The PLC-5/40, -5/40E, -5/40L controllers have a limit of 32K words per data table file.
2
The PLC-5/60 and -5/60L controllers have a limit of 56K words per program file and 32K words per data table file.
3
The PLC-5/80, -5/80E controllers have 64K words of total data table space with a limit of 56K words per program file and 32K words per data table file.
(1)
(2)
(3)
Controller/
Cat. No.
Maximum
User Memory
Words
Total I/O Maximum
(Any Mix)
Types of Communication Ports
Maximum
Number of
I/O Racks
(Rack
Addresses)
Maximum Number of I/O
Chassis
