Rockwell Automation 1785-Lxxx Enhanced and Ethernet PLC-5 Programmable Controllers User Manual
Page 198

Publication 1785-UM012D-EN-P - July 2005
11-24 Communicating with Devices on an Ethernet Network
HTML Examples - the following examples shows an HTML code segment
in bold with a short description of what you would see on a web browser:
The input image word is I:0 is
(this segment displays the value of the first word of the input image table in the
default format of octal with bold type)
The time values in T4:0 are
(this segment will display the values of the timer in T4:0 in the default format of a
table)
I:0 is <,b>
(this segment displays the value of the first word of the input image table in decimal
with bold type)
T4:0 is
(this segment displays the values of the three words comprising timer T4:0 in decimal
with bold type)
N24:0 to n24:3 are
(this segment displays the values of the four words in N24:0 through N24:3 in
decimal with bold type)
S:21-S:23 are
(this segment displays the values of the three words in S:21 through S:23 in decimal
with bold type)
Generating Custom Data Table Monitor Pages
You can generate Custom Data Table Monitor pages with your text editor and
then download them to the PLC-5 controller. The first element of the file must
contain a special tag as follows:
where xx is the automatic refresh rate in seconds (01-99).
A value outside the range defaults to a “snapshot” display.
You can modify the refresh rate three different ways:
•
enter the desired refresh rate and press the
Change
button
•
select the default button for a 15 second refresh
•
disable the refresh by selecting the disable button
