C200 2-33
Specifying machine functions (software switch settings) 2
2.5.17 Specifying transmission source information for IP address fax transmissions and IP
relay operations (mode 351)
Specify the transmission source information for IP relay operations or for forwarding received IP address fax
documents.
Factory settings
Specifying the settings
During the production of this unit, the settings in the shaded cells were selected.
2.5.18 Specifying whether transmission source information is added when performing a IP
relay operation, or when forwarding received documents (mode 352)
Specify how transmission source information is added when performing a IP relay operation, or when
forwarding received documents.
Factory settings
Specifying the settings
During the production of this unit, the settings in the shaded cells were selected.
Bits 7654 3210
Settings 0001 1100 (HEX: 1C)
Bits Description Settings Details
7-4 − 0001 *Do not change the settings
for these bits.
3 Specify whether or not the transmission source information
is added to originals sent with a IP relay operation. 0 Not added
1 Added
2 − 1 *Do not change the setting
for this bit.
1 Specify whether the IP address or the device name of the
transmission source is added to the Subject line when a re-
ceived IP address fax document is forwarded. 0 Priority given to device
name
1 Priority given to IP address
0 − 0 *Do not change the setting
for this bit.
Bits 7654 3210
Settings 1101 0000 (HEX: D0)
Bits Description Settings Details
7 − 1 *Do not change the setting
for this bit.
6 Specify where transmission source information is added with
IP relay operations. 0 Outside of the document
1 Inside the document
5 Specify whether or not transmission source information is
added to received documents that are forwarded. (black and
white only) 0 Not added
1 Added
4 Specify where transmission source information is added
when a received document is forwarded. 0 Outside of the document
1 Inside the document
3-0 − 0000 *Do not change the settings
for these bits.
