Remote Office Configuration of the AastraLink Pro 160
41-001190-02 Rev. 01, Rel. 1.2 B-11
Remote Office Configuration of the AastraLink Pro 160 (Server-Side)
Install the Remote IP Phone (Pre-Stage Phone)
7 Press when remote phone is in the Auto-Discovery screen.
If the phone cannot find a UPnP enabled device, it displays “UPnP device not found”. Press .
The phone prompts for the NAT IP address.
8 Enter the Home Router WAN-side IP address. For example: 65.96.171.130
The phone prompts for the SIP port.
9 Enter the SIP port for the Home Router. For example, you can enter 51620.
The Phone prompts for an RTP port.
10 Enter the RTP port for the Home Router. For example, you can enter 51720.
The Phone prompts for an HTTPS port.
11 Enter the HTTPS port for Home Router. For example, you can enter 51510.
Note: For routers with half-cone NAT, or routers that don’t allow separate port forwarding, use the
value of 9600 instead of 51510.
Install the Remote IP Phone (Non-pre-Stage Phone)
12 Press and enter the server external gateway IP address (for example, 65.215.35.80).
The Phone prompts for an HTTP port.
13 Enter the HTTP port start (for example, 51510).
Note: For routers with half-cone NAT, or routers that don’t allow separate port forwarding, use the
value of 9600 instead of 51510.
The Phone prompts for a NAT IP address.
14 Enter the Home Router WAN-side IP address.
The phone prompts for the SIP port.
AastraLink Pro 160 Remote Office Configuration
Step Action
