Reinstalling System Software Using Recovery Mode

41-001190-02 Rev. 01, Rel. 1.2

7-13

Troubleshooting Solutions

Manual Recovery Mode

If the AastraLink did not automatically enter Recovery Mode, but you need to
reprogram the CompactFlash or Onboard flash, you can use the following
procedure to manually initiate recovery mode.

AastraLink Web UI

Step

Action

1

Power off the AastraLink Pro 160.

2

Eject the CompactFlash card from the front of the system. The ejector handle folds over and may
need to be extended from its recessed position before the card can be ejected.

3

Power on the AastraLink Pro 160.

4

After 30 seconds, verify that the AastraLink Pro 160 has entered recovery mode.

The LED flashes a Green/Red/Off pattern when it is in recovery mode.

5

Insert the CompactFlash card, and ensure that it is fully seated in the slot.

6

To access the Recovery Mode UI, use a web browser and enter the following address:

http:// < DHCP client address received on the LAN interface>

NOTE: If you do not know the IP address of the LAN interface, see

“Obtaining the IP Address of Your

AastraLink Pro 160”

on

page 7-14

.

The AastraLink Recovery Mode UI appears. To set the AastraLink Pro 160 back to its factory default
settings, use the procedure described

“Reprogramming the CompactFlash Card”

on

page 7-17

.
