MAN0892-03-EN CH. 12
February 25, 2010 Page 69 of 109 #1039
CHAPTER 12: REGISTERS
12.1
QX351 Resources
12.1.1 Overview
This section defines the resource limits that a programmer needs to know when writing a program using
the QX351. The QX351 combines operator interface (display and keypad), local and remote I/O (analog
and digital), networking, and controller, into a single product. In addition, the QX351 has graphical
capabilities. The controller portion of the QX351 products is programmed in ladder logic via the Windows-
based Cscape (Control Station Central Application Programming Environment) package.
12.1.2 Resource Limits
Table 12.1 Resource Limits
Resource QX351
%S 1 bit 256
%SR 16 bit 192
%T 1 bit 2048
%M 1 bit 2048
%R 16 bit 9999
%K 1 bit 5
%D 1 bit 1023
%I 1 bit 2048
%Q 1 bit 2048
%AI 16 bit 512
%AQ 16 bit 512
%IG 1 bit 64 (Per ID)
%QG 1 bit 64 (Per ID)
%AIG 16 bit 32 (Per ID)
%AQG 16 bit 32 (Per ID)
Ethernet
CsCAN, Ping, EGD, SRTP, Modbus TCP Master (Downloadable protocol) & Slave, Ethernet IP,
FTP, or HTTP @ 10 MBd or 100 MBd
CsCAN
125 kBd, 250 kBd, 500 kBd, or
1 MBd
Serial Ports 2 RS-232 / RS-485 Ports. Software Selectable.
IDs Per CsCAN
Network
64 w/o repeat (253 w/ 3 repeaters)
SmartStack
Modules
2 (Main Slots) + (6 [Fox Base] x 4 [Smart Stack]) = 26
Main slot will support upto 2 Smart Stack units. Upto 24 Smart Stack units can be connected using
6 Fox bases (Each Fox base supports upto 4 Smart Stack units)
Keypad 5 user-defined Function keys and a System key
Display Type 5.7” QVGA TFT
Display Size 5.7”
Display Screen
Dimensions
320 x 240
Screen
Memory
2.75 MB
Colors 32,768
User Screens 1023
Objects Per
User Screen
50
Ladder Code 256 kB
