Bottom Side
Left Side
Figure 2.1: Visual Overview of QX351
QX Base Model
Network
Screen Type
Standard QX Features
QX351
On-Board Ethernet
100BaseT
5.7"QVGA TFT
LCD with LED
backlight
Micro SD
2 Serial Ports
Ethernet
Battery Cover
Ethernet
USB A
FOX I/O
MJ1
DIP Switches
MJ2
CAN
Power
