MAN0892-03-EN CH. 7
February 25, 2010 Page 31 of 109 #1039
CHAPTER 7: ETHERNET COMMUNICATION
7.1
Ethernet Module Protocols and Features
The following table describes the Ethernet Module Protocols and features supported by QX351.
Protocol / Feature Protocol / Feature Description
ICMP Ping Internet Control Message Protocol
EGD (Peer) GE Fanuc Ethernet Global Data
SRTP Server GE Fanuc Service Request Transfer Protocol
CsCAN TCP Server Horner APG CsCAN over Ethernet
Modbus TCP Slave Modbus over Ethernet
Ethernet / IP Server ODVA CIP over Ethernet
FTP Server File Transfer Protocol
HTTP Server HyperText Transfer Protocol (Web Server)
7.2
Ethernet System Requirements
Full Ethernet functionality requires:
1. PC running Cscape Programming Software Version 8.7 with upgrade or later (for configuration).
2. QX351 controller with onboard Ethernet port.
3. FTP & HTTP protocols.
7.3
Ethernet Module Specifications
Speeds 10 BaseT Ethernet (10-Mbps)
100 BaseTx Fast Ethernet (100-Mbps)
Modes Half or Full Duplex
Auto-Negotiation Both 10/100-Mbps and Half/Full Duplex
Connector Type Shielded RJ-45
Cable Type
(Recommended) CAT5 (or better) UTP
Port Auto MDI/MDI-X
7.4
Ethernet Module Configuration
Note: The following configuration is required for all applications regardless of the protocols used.
Additional configuration procedures must be performed for each protocol used.
To configure the Ethernet Module, use Cscape Programming Software to perform the following steps
1. On the main Cscape screen, select the Controller menu and its I/O Configure sub-menu to
open the I/O Configuration dialog (Figure 7.1)
2. If configuring a different OCS Model than the one shown in the I/O Configuration dialog, click
on the topmost Config button, select the desired OCS Model, and then click OK
