Horner APG QX351 OCS HEQX351C103 - Manual (Page 52)

CH.10 MAN0892-03-EN
February 25, 2010 Page 52 of 109 # 1039
Removable Media
The Removable Media Sub-Menu displays the Removable Media Manager. After selecting Removable
Media from the Main Menu, one of four Sub-Menu screens will appear:
If the Removable Media Manager displays files or directories, as in the last example above, there are
several options available:
Del = Delete the highlighted file or directory
DelAll = Delete all files and directories
Format = Format the RM card
SavPgm = Save QX351 application to DEFAULT.PGM
Esc = Cancel current operation (back up one screen)
If a directory name is highlighted, pressing Enter will switch to that directory showing its files and sub-
directories. In a sub-directory, highlighting.. (dot dot) and pressing Enter will move up one directory.
= No RM card has been installed in the
Memory slot
= RM card is installed and initialized, but
contains no files
= RM card is installed and initialized, and
it contains files.
Free bytes indicates the free space on
RM card in bytes.
Total bytes indicates the total capacity
of the card in bytes.
Media Directory
FILENAM1.EXT 508 11-1-06 10:23a
Free bytes: 6382590
Total bytes: 63826944
Del
Del
All For
mat Save
Pgm
Esc
Media Directory
Media Card Not Present
Free bytes:
Total bytes:
Del
Del
All For
mat Save
Pgm
Esc
