Triton BathyPro - Manual (Page 59)

Figure 26. Navigation Processings Settings dialog box
TABLE 2. Navigation Processings Settings parameters
Parameter Parameter Meanings
XY position You choose an XY position setting depending on whether you
wish to use the Ship position or the Sensor position from the
XTF file.
• Ship: The Ship position should only be used in special
cases. For example, when there is both a towed sensor
and a hull-mounted sensor in use, choosing Ship position
is appropriate.
• Sensor: By default, Isis writes the navigation data to the
Sensor XY position.
• Filter Strength: Enter a single digit in the range 1-9. The
higher the number the stronger the filtering (or
smoothing) of the navigation data.
June 2004 BathyPro User’s Manual
59
