Boonton 4540 Series RF Power Meter
Getting Started 3-12
Table 3-3. Initialized Parameters (continued)
Parameter Applies to: Default
Parameters Related to the Time > Menu
Timebase Pulse Mode 100 µs/Div
Timebase Modulated Mode 200 ms/Div
Position Pulse Mode 5.0
Position Control Pulse Mode Vernier
Trig Delay Pulse Mode 0 µs
Parameters Related to the Disp > Menu
Beep On
Backlight (Menu)
Brightness (not changed by init)
Delay Time (not changed by init)
Screen Saver Brightness (not changed by init)
Screen Saver On/Off (not changed by init)
Format (Menu)
Grid Type (not changed by init)
Trace Type All Channels (not changed by init)
Disp Header (not changed by init)
Set Colors (not changed by init)
Graph Header(Menu)
Number of Rows 3
Field Parameters Pulse Mode See Table 3-3-1
Text Mode(Menu)
Channel 1|2 Source Modulated Mode Average CW Power
Channel 1|2 Options
Secondary Field 1 Modulated Mode Minimum Power
Secondary Field 2 Modulated Mode Maximum Power
Parameters Related to the Markers > Menu
Marker 1 Pulse Mode -250 µs
Marker 2 Pulse Mode 250 µs
Parameters Related to the System > Menu
IO Config (Menu)
GPIB (Menu) (not changed by init)
Ethernet (Menu) (not changed by init)
Multi-IO (Menu)
IO Mode Off
Calibrator (Menu)
Cal Output Off
Level 0.0 dBm
Select Calibrator Internal
