Boonton 4540 Series RF Power Meter

Remote Operation

5-44

OUTPut:MIO:TRIGout:SOURce

Description:

Set/return Multi IO source for trigger out mode. Below is a description of each argument:

Argument

Description

INT1, INT2:

Multi IO output is active when selected internal trigger is active.

EXT:

Multi IO output is active when external trigger is active.

SWEEP:

Pulses when actual trigger event occurs.

Syntax:

OUTPut:MIO:TRIGout:SOURce

Argument:

= { INT1, INT2, EXT, SWEEP}

Valid Modes:

Any

OUTPut:MIO:VOLTage

Description:

Set/return Multi IO user set voltage out.

Syntax:

OUTPut:MIO:VOLTage:SOURce

Argument:

< numeric_value > = -10.0 to + 10.0 V

Valid Modes:

Any
