Boonton 4540 Series RF Power Meter
Remote Operation 5-92
Table 5-1. SCPI COMMAND SUMMARY (continued)
SYSTem:TIMe:MINUTE
Set/get minute. = 0 to 59
SYSTem:VERSion?
Return SCPI version compliance. = yyyy.v
TRACe[1|2]:[MIN|MAX|AVERage]:DATA[:NEXT]?
Return count min, max or average power samples starting at index
TRACe[1|2]:[MIN|MAX|AVERage]:DUMP?
Return entire min, max or average power trace as binary block
TRACe[1|2]:COUNt
Set/return total number of trace pwr points to
return. =
1 to 501
TRACe[1|2]:INDEX Set/return index of the next trace power point. =
0 to 500
TRACe:DELImiter
Set/return the field delimiter used in the TRACe:DATA? query
return string. < character data > = COMMA, CR, LF, SPACE
TRIGger:CDF:COUNt
Set/return Statistical Mode terminal count. = 1 to
4000 megasamples
TRIGger:CDF:DECImate
Set/return perform decimation when terminal count is reached.
= { 0, 1, OFF, ON }
TRIGger:CDF:TIMe
Set/return Statistical Mode terminal time. = 1 to
3600 sec
TRIGger:DELay
Set/return trigger delay with respect to the trigger.
= see Specifications Section 1-6.
TRIGger:HOLDoff
Set/return trigger holdoff time. = 0 to 1 sec in 10
ns increments
TRIGger:LEVel
Set/return trigger level.
Internal Trigger: = -40 to +20 dBm plus offset.
External Trigger: = ±5 volts
TRIGger:MODE
Set/return trigger mode on display. < character data > =
AUTOPKPK, AUTO, NORMAL, FREERUN
TRIGger:POSition
Set/return trigger position on display. < character data > = LEFT,
MIDDLE, RIGHT
TRIGger:SLOPe
Set/return trigger slope on display. = POS, NEG
TRIGger:SOURce
Select trigger source. < character data > = CH1, CH2, EXT
TRIGger:VERNier
Set or return the fine position of the trigger event on
