Boonton 4540 Peak Power Meter User Manual - Manual (Page 107)

Boonton 4540 Series RF Power Meter
Operation 4-59
4.5.36 System > I/O Config Menu
The I/O Config menu provides access to set GPIB address and configure Ethernet, and Multi IO port.
Main Pg 2 > System > GPIB Address
Description: Set the GPIB Address. Press the menu key to obtain
the number entry popup. The address entered appears
in the menu box.
Menu Type: Numeric Value.
Range: 1 to 30
SCPI Command: SYSTem:COMMunicate:GPIB:ADDRess
Note
Using the SCPI command to change the GPIB bus address
while using the GPIB bus will interrupt bus communication.
Main Pg 2 > System > Ethernet
Description: Access the Ethernet configuration menu.
Menu Type: Menu Select.
Main Pg 2 > System > GPIB
Description: Access the Multi IO configuration menu.
Menu Type: Menu Select.
Fig. 4-47 I/O Config Menu
