Boonton 4540 Series RF Power Meter
Remote Operation 5-87
Table 5-1. SCPI COMMAND SUMMARY (continued)
OUTPut:EXTernal:SIGNal
Set or return the on/off state of the external 1 GHz calibrator
output signal.
OUTPut:INTernal:LEVel[:POWer]
Set or return the power level of the internal 50 MHz calibrator
output signal.
OUTPut:INTernal:SIGNal
Set or return the on/off state of the internal 50 MHz output signal.
OUTPut:MIO:MODe
Set/return Multi IO mode. = OFF, STATus,
RECOrder, TRIGger, VOLTage
OUTPut:[MIO:]RECOroder:FORCe
Command sets the Multi IO to voltage mode and sets the output
voltage to the argument. = -10.0 to + 10.0 V
OUTPut:[MIO:]RECOroder:MAX
Set or return the Multi IO recorder output maximum, or full scale
(+10.0V) power reference level. = -200.00 to
+200.00 dBm
OUTPut:[MIO:]RECOroderMIN
Set or return the Multi IO recorder output minimum, or downscale
(-10.0V or 0.0V) power reference level. =
-200.00 to +200.00 dBm
OUTPut:[MIO:]RECOroder:POLarity
Set or return the recorder output polarity. =
UNIPOLAR, BIPOLAR
OUTPut:[MIO:]RECOroder:SCALing
Set or return the Multi IO measurement mode when in recorder
mode. = AUTO, MANUAL
OUTPut:[MIO:]RECOroder:SOURce
Set or return the source channel for the Multi IO recorder
output. = CH1, CH2
OUTPut:MIO:STATus:SETTing
Set/return Multi IO status out setting. =
ALMACT, ALMLATCH, MEASRDY, CAL
OUTPut:MIO:STATus:SOURce
Set/return Multi IO source for status out (alarm).
= CH1, CH2, BOTH
OUTPut:MIO:TRIGout:SOURce
Set/return Multi IO source for trigger out mode. =
INT1, INT2, EXT, SWEEP
OUTPut:MIO:VOLTage
Set/return Multi IO user set voltage out.< numeric_value > = -10.0
to + 10.0
