Enclosure KVM 51

except PrtSc are sent to the server, along with the KVM mouse. To exit the server console and return to

the KVM Menu, press Prt Scrn.

NOTE:

For resolutions 1024x768 through 1600x1200, the screen resolution matches the server

console screen resolution. Server console resolutions below 1024x768 result with a display on a

portion of the Onboard Administrator KVM screen in 1024x768 mode. For server console

resolutions above 1600x1200, a warning message displays, and you are brought back to the

Enclosure KVM Menu screen.

•

Server Power—Select this power icon for a server to change the server power state.

•

Server DVD—Select this DVD icon for a server to change the enclosure DVD connection for this server.

•

Server Health—Select this health icon to display the current health state for that server.

•

Insight Display—Select the Insight Display button to access Insight Display screens from the KVM Menu.
