Configuring the HP BladeSystem c7000 enclosure and enclosure devices 239
To view available Management Console address links (IPv4 and IPv6), click the down arrow alongside the
Management URL address. A popup appears, as in the following figure. When FQDN link support is
enabled and certain DNS configuration requirements are met, an FQDN-based address displays as the
default Management URL (as shown). For more information about enabling FQDN link support, see the
)" page.
Column
Description
Check box
Click the check boxes next to the bay or bays where you want to apply the Virtual
Power and UID State features.
Bay
Bay in the enclosure of the corresponding interconnect device. This field displays only
populated bays. Empty bays are not displayed in this table.
Status
Overall status of the interconnect device. Possible values are Unknown, OK,
Degraded, and Failed.
UID
Status of the UID on the interconnect device. Possible values are On (blue) or Off (gray).
Power State
Power state of the interconnect device. Possible values are On or Off.
Module Type
Network interface type for the interconnect device installed in this bay. Possible values
are Ethernet or fiber.
Management URL
IPv4 address where the interconnect device can be managed and configured for use in
the network. To view available Management URL address links (IPv4 and IPv6), click
the down arrow to display a dropdown menu.
When FQDN link support is enabled and certain DNS configuration requirements are
met, an FQDN-based address displays as the default Management URL. For more
information about enabling FQDN link support, see the "Network Access (on page
)" page.
Product Name
Common descriptive name for the interconnect device.
Information on this page is current as of the last download. To view updated information, click Refresh.
