NOTE:
•
Sometimes Standard, High Speed, and Initiator/External MIX modes are collectively referred to
as
Fibre PCB modes. PCB is an acronym for printed circuit board. The array documentation
sometimes uses the term PCB when referring to a channel adapter, which is a printed circuit board
used for connecting hosts and an array.
• Storage partition administrators cannot apply High Speed or Initiator/External MIX mode.
Table 2 Port serial numbers and names (4-port channel adapters)
High Speed or
Initiator/External
MIX mode
1
Standard mode
1 Port
serial
number High Speed or
Initiator/External
MIX mode
1
Standard mode
1 Port
serial
number
CL2-A CL2-A 128 CL1-A CL1-A 0
CL4-A [2-A 2nd] CL4-A 129 CL3-A [1-A 2nd] CL3-A 1
– – 130 – – 2
– – 131 – – 3
– – 132 – – 4
– – 133 – – 5
– – 134 – – 6
– – 135 – – 7
CL2-C CL2-C 136 CL1-C CL1-C 8
CL4-C [2-C 2nd] CL4-C 137 CL3-C [1-C 2nd] CL3-C 9
– – 138 – – 10
– – 139 – – 11
– – 140 – – 12
– – 141 – – 13
– – 142 – – 14
– – 143 – – 15
CL2-E CL2-E 144 CL1-E CL1-E 16
CL4-E [2-E 2nd] CL4-E 145 CL3-E [1-E 2nd] CL3-E 17
– – 146 – – 18
– – 147 – – 19
– – 148 – – 20
– – 149 – – 21
