NOTE:
If a parity group number starts with E (for example, E1-1), the parity group consists of one or
more external LUs.
NOTE:
If a parity group number starts with V (for example, V1-1), the parity group consists of one or
more virtual volumes (V-VOLs).
•
Paths: Number of paths set for the LDEV. If this column displays the number of paths for an LDEV,
you can use the LDEV as the top LDEV of a LUSE volume (see
Volume Manager operations using
).
•
Access Attribute: Access attribute set for the LDEV.
•
IO Suppression Mode: Displays Disable when the I/O request for the external volume from the
host is suppressed. Displays Enable when the I/O request for the external volume from the host is
not suppressed.
•
Cache Mode: Displays Disable when the local storage system cache memory is set to be unused
for responding to the I/O request for the external volume from the host. Displays Enable when the
local storage system cache memory is set to be used for responding to the I/O request for the
external volume from the host.
•
Ex-Dev Info.: Displays the LDEV's drive type. Displays an asterisk (*) when the drive type is SATA.
Displays nothing when the drive type is not SATA.
•
CLPR: ID of the cache logical partition (CLPR) to which the displayed volumes belong. The CLPR
ID is composed of a CLPR number (two-digit) and a CLPR name (maximum of 16 characters)
Capacity Unit box
Capacity of the LDEV displayed in the Capacity column, in either GB (default) or MB.
Selected LDEVs
Number of LDEVs selected in the LDEV Information table.
Select an LDEV list
Displays the selected CU's LDEVs, CVS volumes, and LUSE volumes that are eligible to become part
of a LUSE volume. The selected LDEV number becomes the top LDEV number of a LUSE volume.
Volume Count list
Number of LDEVs forming a LUSE volume.
For example, if you select 3 in the Volume Count list, three LDEVs are expected to form a LUSE volume
and three LDEVs are added to the Expanded LDEVs list.
