Control panel overview, Control panel features – HP Photosmart C6340 All-in-One Printer User Manual
Page 13

Label
Description
8
Photo tray
9
Ink cartridge door
10
Glass
11
Lid backing
12
Rear door
13
Ethernet port
14
Rear USB port
15
Power connection*
* Use only with the power adapter supplied by HP.
Control panel overview
This section describes the functions of the control panel buttons and lights, as well as the
icons and sleep state on the display.
This section contains the following topics:
•
•
•
Control panel features
The following diagram and related table provide a quick reference to the HP All-in-One
control panel features.
Label
Icon
Name and Description
1
Color graphics display (also referred to as the display): Displays menus, photos, and
messages. The display can be pulled up and angled for better viewing.
2
Home: Returns to the Home screen (the default screen when you turn on the
product).
Chapter 2
(continued)
10
HP All-in-One overview
Ov
er
vi
ew
