P741 [-01]
...
[-23]
Process Data Bus Out
(Process data Bus Out)
S
0000 ... FFFF (hex) This parameter provides
information about the actual
status word and the actual
values that are transferred
via the bus systems.
[-01] = Status word
Status word, source from
P509.
[-02] = Actual value 1 (P543 [-01])
[-03] = Actual value 2 (P543 [-02])
[-04] = Actual value 3 (P543 [-03])
[-05] = Actual value 4 (P543 [-04])
[-06] = Actual value 5 (P543 [-05])
[-07] = Bus I/O Out Bit (P481)
The displayed value depicts
all Bus OUT Bit sources linked
with "OR".
[-08 ] = Parameter data Out 1
[-09 ] = Parameter data Out 2
[-10 ] = Parameter data Out 3
[-11 ] = Parameter data Out 4
[-12 ] = Parameter data Out 5
Data during parameter
transfer.
[-13] = Actual value 1 master
function
[-14] = Actual value 2 master
function
[-15] = Actual value 3 master
function
[-16] = Actual value 4 master
function
[-17] = Actual value 5 master
function
Actual value of master
function P502 / P503.
[-18] = PLC status word Status word via PLC
[-19] = Actual value 1 PLC
[-20] = Actual value 2 PLC
[-21] = Actual value 3 PLC
[-22] = Actual value 4 PLC
[-23] = Actual value 5 PLC
Actual value data via PLC
Pos : 167 /Anleit ungen/5. / 6. Parametrier ung [BU 0500 / BU 0200]/ Par ameter/ P700-P799/ Paramet er P745 – Baugruppen Versi on @ 0\ mod_1328178182499_388. doc x @ 13474 @ @ 1
P745
Module version
(Module version)
-3276.8 ... 3276.8 Version status (software version) of the technology unit (SK TU3-xxx), but only when own
processor is present, i.e. not for SK TU3-CTR.
Have this data available if you have a technical query.
Pos : 168 /Anleit ungen/5. / 6. Parametrier ung [BU 0500 / BU 0200]/ Par ameter/ P700-P799/ Paramet er P746 – Baugruppen Z ust and PBR [ SK 5xxE] @ 1\ mod_1335793579623_388.doc x @ 25168 @ @ 1
P746
Module status
(Module status)
S
0000 ... FFFF (hex) Shows the actual status (readiness, error, communication) of the technology unit (SK TU3-xxx),
but only when own processor is present, i.e. not for SK TU3-CTR.
Example:
0603
hex
High byte = 06
hex
à Profibus
Low byte = 03
hex
à Module ready + connection to master
Details of the codes specific to the bus can be found in the section "Error monitoring" of the
relevant supplementary instructions.
