5 Parameters
BU 0060 GB-4112 71
P509
Interface
(Interface)
0 ... 21
{ 0 }
Selection of the interface via which the FI is controlled.
0 = Control terminals or keyboard control ** with the ControlBox (if P510=0), the
ParameterBox (not ext. P-box) or via BUS I/O Bits.
1 = Only control terminals , the FI can only be controlled via the digital and analog
inputs or via the bus I/O Bits.
5 = CAN setpoint*, the frequency setpoint is transferred via CAN. Control via the digital
inputs is still active.
6 = CAN control word*, the control signals (enable, direction of rotation, ...) are
transferred via UCAN, the setpoint via the analog input or the fixed frequencies.
7 = CAN*, all control data is transferred via CAN. The analog input and the digital inputs
have no function (except safety functions)
11 = CAN Broadcast*, the inverter receives all of the control data via CAN without
responding to the master (e.g. for the synchronisation function). The analog input and
the digital inputs have no function (except safety functions)
15 = CANopen setpoint*, as for setting 5, but CANopen
16 = CANopen control word*, as for setting 6, but CANopen
17 = CANopen*, as for setting 7, but CANopen
*) Keyboard control (ControlBox, ParameterBox) is blocked, parameterisation is still possible.
**) If the communication during keyboard control is interrupted (time out 0.5 sec),
the FI will block without an error message.
Pos : 118 /Anleit ungen/5. / 6. Parametrier ung [BU 0500 / BU 0200]/ Par ameter/ P500-P599/ Paramet er P510 – Sc hni ttst elle Bus nebens oll wert e [SK 700E] @ 1\ mod_1335780555886_388. doc x @ 24850 @ @ 1
P510
Bus interface auxiliary setpoint
(Bus interface auxiliary setpoints)
SK 700E/
SK750E
S
0 ... 8
{ all 0 }
Selection of the interface via which the FI is controlled.
0 = Auto (=P509): The source of the auxiliary setpoint is automatically derived from the
setting in the parameter P509 >Interface<
1 = USS
2 = CANbus
3 = Profibus
4 = InterBus
5 = CANopen
6 = DeviceNet
7 = Reserved
8 = CAN Broadcast
