5 Parameters
BU 0060 GB-4112 87
P740 [-01]
...
[-23]
Process Data Bus In
(Process data Bus In)
S
0000 ... FFFF (hex) This parameter informs
about the actual control
word and the setpoints that
are transferred via the bus
systems.
For display, a BUS system
must be selected in P509
[-01 ] = Control word
Control word, source from
P509.
[-02] = setpoint value 1
[-03] = setpoint value 2
[-04] = setpoint value 3
[-05] = setpoint value 4
[-06] = setpoint value 5
Setpoint data from main
setpoint (P510 [-01]).
[-07] = Bus I/O In Bits (P480)
The displayed value depicts all
Bus In Bit sources linked with
"OR".
[-08] = Parameter data In 1
[-09] = Parameter data In 2
[-10] = Parameter data In 3
[-11] = Parameter data In 4
[-12] = Parameter data In 5
Data during parameter transfer:
Order label (AK),Parameter
number (PNU), Index (IND),
Parameter value (PWE 1/2)
[-13] = setpoint value 1
[-14] = setpoint value 2
[-15] = setpoint value 3
[-16] = setpoint value 4
[-17] = setpoint value 5
Setpoint data from the master
function value (Broadcast), if
P509 = 9/10
(P510 [-02])
[-18] = PLC control word Control word, source PLC
[-19] = setpoint value 1
[-20] = setpoint value 2
[-21] = setpoint value 3
[-22] = setpoint value 4
[-23] = setpoint value 5
Setpoint data from the PLC.
