Installation and Operating Instructions OPTIMASS

95

6.3 Functional Tests and Troubleshooting

Min. and Max. recorded temperature (menu 5.4):
Records the maximum values of temperature and strain as experienced by the transducer.

Maximum

Minimum

OPTIMASS 7000 - Titanium

150°C or 302°F

-40 °C or –40°F

OPTIMASS 7000 - Hastelloy 100°C or 212°F

0°C or 32°F

OPTIMASS 7000 – SS
Optional

100°C or 212°F
130°C or 266°F

0°C or 32°F

OPTIMASS 3000 (7100) –
SS or Hastelloy

150°C or 302°F

–30 °C or –22°F

OPTIMASS 8000 *
(Depending on variant)

230°C or 446°F

–180 °C or –
292°F

Max. operating temperature:

OPTIMASS 9000

350°C or 662°F

0°C or 32°F


Application problems that appear to be Transducer Faults
• Leaky Valves will cause high zeros
• Entrained Air/gas will cause high energy levels and high zero
• Product coating on the inside of the tube will cause high/low density and high zero

The following faults have occurred (listed below with their symptoms):

Beware:
Application problems can cause similar symptoms, check this first!

Tube bore slightly eroded or corroded
• Density Low
• Frequency High
• Small Mass Flow Errors

Tube eroded or corroded through (fluid in housing)
• Tube will not start
• If fluid conductive - low resistance to ground

Open Circuit Drivers, Sensors, RTD’s and Strain Gauges
• Detectable with Ohm meter

Typical Frequency values ( at 20

°C / 68°F)

Titanium SS

Hastelloy

Model Size

Empty Water Empty Water Empty Water

3000 - 01

137 ± 3

133 ± 3

141 ± 3

137 ± 3

3000 - 03

137 ± 3

133 ± 3

141 ± 3

137 ± 3

3000 - 04

195 ± 5

185 ± 5

195 ± 5

185 ± 5

7000 - 06

316 ± 10

301 ± 10

374 ± 6

361 ± 7

7000 - 10

402 ± 10

367 ± 10

419 ± 15

394 ± 15

439 ± 7

415 ± 6

7000 - 15

507 ± 7

436 ± 6

573 ± 15

514 ± 15

574 ± 27

517 ± 27

7000 - 25

619 ± 6

488 ± 6

701 ±10

589 ± 10

693 ± 10

586 ± 10

7000 - 40

571 ± 6

415 ± 6

642 ± 10

509 ± 10

633 ± 6

506 ± 6

7000 - 50

539 ± 5

375 ± 5

550 ± 14

435 ± 14

582 ± 11

453 ± 11

7000 - 80

497 ± 5

349 ± 5

502 ± 10

378 ± 12

492 ± 12

369 ± 12

8/9000 – 15

146 ± 3

136 ± 3

146 ± 3

136 ± 3

8/9000 - 25

181 ± 3

162 ± 3

181 ± 3

162 ± 3

8/9000 - 40

192 ± 3

164 ± 3

192 ± 3

164 ± 3

8/9000 - 80

119 ± 3

101 ± 3

119 ± 3

101 ± 3

8/9000 - 100

149 ± 3

117 ± 3

149 ± 3

117 ± 3
