Installation and Operating Instructions OPTIMASS 88
Alarm Output – Menu 4.6
Function Fct. 4.6.1.
Any one of the following may be programmed / selected for the alarm output.
Key
Fct. 4.2.1. Function
Off no alarm function
Mass flow
Density
Mass total
Volume flow
Volume total
Temperature
Direction
Severe Error
All Errors
I1 Sat. (Current S/P 1 Saturated)
I2 Sat. (Current S/P 2 Saturated)
I3 Sat. (Current S/P 3 Saturated)
Pulse Sat. (Pulse output Saturated)
Any op. Sat. (Any output Saturated)
Velocity
Additional (The range for the additional / second totalizer Saturated)
Active Level Fct. 4.6.2.
Allows the selection of the alarm level. High or Low.
(Normally open or normally closed).
Active high or active low.
Control Input – Menu 4.7
This menu allows the setting of certain functions via an external input (contact or binary).
Function Fct 4.7.1
Choose one of the following:
Inactive Option not required.
Standby This option puts the meter into a standby mode where the tube is still vibrated,
but the outputs are frozen to zero. Can be used for example during a cleaning
process. Meter will resume measurement mode almost instantaneously once
contact is removed.
Stop This option stops the meter vibrating and shuts all the measurements down. When
the contact is removed, the meter will go though its plausibility checks before
resuming measurement mode. This will take a few seconds.
Zero Calib. This option will initiate a zero calibration externally generated via a push button or
a contact from a valve or pump.
Total Reset Will allow the resetting of the totalizer remotely (the option in menu 3.5.3 needs to
be enabled).
Quit errors Allows the acceptance and quitting of errors remotely.
Active Level Fct. 4.7.2
This allows the contact to be high or low (normally open or normally closed) as before.
