Installation and Operating Instructions OPTIMASS 100
Terminal Labels for MFC 050 Housing Pack of 10
Opt 1: 1 x 4-20 mA, 1 x Pulse, 1 x Control input, 1 x Status output-HART X386054
Opt 2: 1 x 4-20 mA, Modbus X386056
Opt 3: 1 x 4-20 mA, 1 x Control input, 1 x dual phase frequency output-HART X586057
Opt 4: 2 x 4-20 mA, 1 x Pulse, 1 x Control input-HART X386058
Opt 5: 2 x 4-20 mA, 1 x Status output, 1 x Control input-HART X386055
Opt 6: 3 x 4-20 mA, 1 x Pulse-HART X886059
Opt 7: 3 x 4-20 mA, 1 x Control input-HART X386050
Opt 8: 3 x 4-20 mA, 1 x Status output-HART X386061
Terminal Labels for MFC 051 Housing
(IS outputs) Pack of 10
Opt 1: 2 x 4-20 mA, outputs X3159050300
Opt 2: 1 x 4-20 mA, 1 x pulse X3159050200
Opt 3: 1 x 4-20 mA, 1 x control i/p X3159050200
Opt 4: 1 x 4-20 mA, 1 x status o/p X3159050200
Opt 5: 1 x 4-20 mA, 1 x Profibus PA X3159050400
’O’ Ring for Aseptic Unions to DIN 11864-2 –Form A (FDA Compliant)
Size
DN10
X5874809989
DN15 X5874819989
DN25 X5874829989
DN40 X5874839989
DN50 X5874849989
DN80 X5874859989
Accessories
Housing Lid Wrench
X3310380200
Magnetic Pin for Programming XVX20705300
Terminal Screwdriver X5870949989
Grey Non-Ex remote cable X5871059989
Blue Ex (intrinsically safe) remote cable X5871069989
Remote cable preparation kit X1870349989
Conversion kit - Compact to Remote (without cable) X1870309989
Conversion kit - Remote to Compact X1870319989
Terminal Separation Kit for IS housing X1870359989
Service Tools
Simulator SIM 500 (complete with all cables and software) 220V
1861009989
Simulator SIM 500 (complete with all cables and software) 100 / 120V 1861109989
Spare simulator comms. cable (RS 232) 5873329989
Service harness (converter to PC/simulator) 1861019989
USB to 9 pin RS 232 serial converter for service harness or SIM 500 5870269989
Toolbox software only 3861159989
Note :
1. For service : Order service harness and software (for laptops with RS232 ports)
2. For service : Order service harness and software plus USB converter (for laptops with USB
ports only)
