Installation and Operating Instructions OPTIMASS 86
Menu 3.6 Settings
This menu allows a Tag or ID number to be programmed. A combination of alphanumeric characters is
available.
Display Key
Line 1 Line 2
From Fct. 3.6.1 Tag ID
→ Allows the programming of a Tag number.
The ↑ provides the selection of character required while the → allows the selection of the
next character to be selected. When complete the ↵ button must be pressed.
5.4 Menu 4 - I/O Configuration
The actual output configuration can be read out in Fct. 4.1 I.O. FITTED. The menu 4.1 is “Read only” for
the output options 1, 2 and 3 of the MFC 050 converter and for all options for the MFC 051 converter.
For the output options 4 to 8 the user can select between the following configuration options:
Fct. 4.1 I/O Fitted
Key
Fct. 4.1. I.O. FITTED
2I A B Option 4 (2 current op, 1 alarm op, 1 control ip)
2I F B Option 5 (2 current op, 1 pulse/frequency op, 1 control ip)
3I F Option 6 (3 current op, 1 pulse/frequency op)
3I B Option 7 (3 current op, 1 control ip)
3I A Option 8 (3 current op, 1 alarm op)
After every change of the output configuration in Fct. 4.1 all current outputs needs recalibration (see Fct.
4.10).
For the configuration of the input/outputs see chapter 4.4 “Table of programmable functions”
Current Output 1 - Menu 4.2
Function Fct. 4.2.1.
This menu allows the allocation of one of the following functions to the output current (first 4-20 mA).
Key
Fct. 4.2.1. Function
Off
No function allocated. No output.
Mass flow Process functions
Density Process functions
Volume flow Process functions
Temperature Process functions
Direction Process functions
Sensor Ave. for diagnostic purposes)
Sensor Dev. for diagnostic purposes)
Drive Energy for diagnostic purposes)
Tube frequency for diagnostic purposes)
Strain MT (for diagnostic purposes – strain on measuring tube)
Strain IC (for diagnostic purposes – strain on Inner cylinder)
Velocity Process functions
Once option is selected press ↵ to save.
