Installation and Operating Instructions OPTIMASS 60
Fct.
No Text Description and settings
3 CONFIG Main menu 3 Configuration
3.1 BASIS.PARAM Submenu 3.1 Base data
3.1.1 L.F. CUTOFF Low flow cut-off
Value: 0 to 10 percent of nominal flow
3.1.2 TIME CONST. Time constant for output of measured values
Range 0,2 ... 20 sec.
3.1.3 FLOW MODE Define whether bi-directional or uni-directional flow is expected.
Select either:
* FLOW > 0 (Ignore negative flows)
* FLOW < 0 (Ignore positive flows)
* FLOW +/- (Allow positive and negative flows)
3.1.4 FLOW DIR. Define direction of flow
Select either FORWARD or BACKWARD
3.1.5 PIPE DIAM. Select the pipe diameter
Input of the pipe diameter in mm for the flow velocity measurement.
Default value: Tube diameter for the sensor size
3.1.6 ADD. TOTAL Use the key ↑ to add one additional totaliser
Select, then press ↵:
* NONE
* MASS TOTAL
* VOLUME TOT
* CONC.TOTAL.
3.1.7 ERROR MSG Which status messages to be displayed?
Use the key ↑ to select, then press ↵
* BASIC.ERROR
* TRANS.ERROR
* I.O. ERRORS
* ALL ERRORS
3.1.8 PRESS TIME Pressure Suppression Time
Range: 0.0 (OFF) … 20.0 Seconds
3.1.9 PRESS CUTOF Pressure Suppression Cut Off
Range: 0.0 … 10.0%
3.2 DISPLAY Submenu 3.2 DISPLAY
3.2.1 CYCL. DISP. Cyclic display required?
Setting STATIC.DISP. or CYCLE.DISP. If CYCLE.DISP. is selected then in
measurement mode the display will switch from Mass Flow to Density to Total to
Temperature every 5 seconds.
3.2.2 MASS FLOW Units and format for mass flow display
* g, kg, t, oz, lb per s, min, h, d
* Number of digits after the decimal point selectable.
3.2.3 TOTAL MASS. Units and format for totaliser
* g, kg, t, oz, lb
* Number of digits after the decimal point selectable.
3.2.4 VOLUME.FLOW Units and format for volume flow
* Select OFF (no volume flow display) or
* cm3, dm3, litre, m3 , in3 ,ft3 , USgal, or gallon per
* s, min, hr, day
* Number of digits after the decimal point selectable.
3.2.5 VOL.TOTAL Units and format for totalizer
* Select OFF (no volume total display) or cm3, dm3, liter, m3, inch3, ft3, US gal, gallon.
3.2.6 TEMPERATUR. Units for temperature
* °C or °F
* Format fixed at 1 decimal place
3.2.7 DENSITY Units and format for density
* g, kg, t, per cm3, dm3, litre, m3 or oz, lb per in3 ,ft3 , USgal, gallon or SG (Specific Gravity
relative to water at 20°C)
* Number of digits after the decimal point selectable.
3.2.8 CONC. FLOW Units and format for mass flow of dissolved medium
* Select OFF (no mass flow rate of the dissolved medium on display) or
* g, kg, t, oz, lb per s, min, h, d
* Number of digits after the decimal point selectable.
3.2.9 CONC. TOTAL Units and format for mass totaliser of dissolved medium
* Select OFF (no mass flow total of the dissolved medium on display) or
* g, kg, t, oz, lb
* Number of digits after the decimal point selectable.
3.2.10 CONC.BY.
MASS
Monitor concentration by mass
* Select OFF (no concentration by mass on display or
* PERCENT M
