TECHNICAL DATA
8
97
OPTISONIC 3400
www.krohne.com 11/2013 - 4002037702 - HB OPTISONIC 3400 -en-R02
Electrical connections Electrical connections Electrical connections Electrical connections
Description of used abbreviations; Q=xxx; I
max
= maximum current; Ui
n
= xxx; U
int
= internal voltage; U
ext
= external voltage; U
int, max
= maximal internal voltage
General Electrical connection is carried out in conformity with the
VDE 0100 directive "Regulations for electrical power
installations with line voltages up to 1000 V" or equivalent
national specifications.
Power supply Standard: 100…230 VAC (-15% / +10%), 50/60 Hz
Option: 24 VAC/DC (AC: -15% / +10%; DC: -25% / +30%)
Power consumption AC: 22 VA
DC: 12 W
Signal cable
(remote version only)
MR06 (shielded cable with 6 coax cores): Ø 10.6 mm / 0.4"
5 m / 16 ft
Option: 10...30 m / 33...98 ft
Cable entries Standard: M20 x 1.5 (8...12 mm)
Option: ½" NPT, PF ½
Inputs and outputs
General All outputs are electrically isolated from each other and
from all other circuits.
All operating data and output values can be adjusted.
Description of used abbreviations U
ext
= external voltage; R
L
= load + resistance;
U
0
= terminal voltage; I
nom
= nominal current
Safety limit values (Ex i):
U
i
= max. input voltage; I
i
= max. input current; P
i
= max.
input power rating;
C
i
= max. input capacity; L
i
= max. input inductivity
