8
TECHNICAL DATA
94
OPTISONIC 3400
www.krohne.com 11/2013 - 4002037702 - HB OPTISONIC 3400 -en-R02
Display and user interface Display and user interface Display and user interface Display and user interface
Graphic display LC display, backlit white
Size: 128x64 pixels, corresponds to 59x31 mm =
2.32"x1.22"
Display turnable in 90° steps.
Operating elements 4 optical and push buttons for operator control of the
signal converter without opening the housing.
Option: Infrared interface (GDC)
Remote operation
PACTware TM including Device Type Manager (DTM)
HART ® handheld communicator (Emerson), AMS
(Emerson), PDM (Siemens)
All DTM's and drivers will be available at the internet
homepage of the manufacturer.
Display functions Display functions Display functions Display functions
Operating menu Programming of parameters at 2 measured value pages,
1 status page, 1 graphic page (measured values and
descriptions adjustable as required)
Language of display texts English, French, German
Measurement functions Units: Units: Units: Units: Metric, British and US units selectable as desired
from lists for volume/mass flow and counting, velocity,
temperature.
Measured values: Measured values: Measured values: Measured values: volume flow, mass flow, flow speed,
velocity of sound, gain, signal to noise ratio, flow
direction, diagnostics
Diagnostic functions Standards: Standards: Standards: Standards: VDI/NAMUR NE 107
Status messages: Status messages: Status messages: Status messages: Output of status messages via display,
current and/or status output, HART
® or via other bus
interface
Sensor diagnostics: Sensor diagnostics: Sensor diagnostics: Sensor diagnostics: per acoustic path velocity of sound,
flow speed, gain, signal to noise ratio
Process diagnostics: Process diagnostics: Process diagnostics: Process diagnostics: empty pipe, signal integrity, cabling,
flow conditions
Signal converter diagnostics: Signal converter diagnostics: Signal converter diagnostics: Signal converter diagnostics: data bus monitoring, I/O
connections, electronics temperature, parameter and
data integrity
Measuring accuracy
Reference conditions Reference conditions Reference conditions Reference conditions
Medium Water
Temperature 20°C / 68°F
Pressure 1 bar / 14.5 psi
Inlet section 10 DN
Maximum measuring error Maximum measuring error Maximum measuring error Maximum measuring error
Standard: ± 0.3% ±2 mm/s of actual measured flow rate
Repeatability ± 0.2%
