DESCRIPTION OF HART INTERFACE
9
127
OPTISONIC 3400
www.krohne.com
11/2013 - 4002037702 - HB OPTISONIC 3400 -en-R02
9.11.2 HART Menu Tree AMS - Device's context menu
AMS supports the following standard EDDL menus:
• Process Variables Root Menu (details on page 130)
• Diagnostic Root Menu (details on page 133)
• Device Root Menu (details on page 135)
The menus are located in the AMS user interface as follows:
Device's context menu
Configure/Setup
Configure/Setup
Configure/Setup
Configure/Setup
Configure/Setup (Device Root Menu)
Compare
Clear Offline
Device Diagnostics
Device Diagnostics
Device Diagnostics
Device Diagnostics
Device Diagnostics (Diagnostic Root Menu)
Process Variables
Process Variables
Process Variables
Process Variables
Process Variables (Process Variables Root Menu)
Scan Device
Calibration Management
Calibration Management
Calibration Management
Calibration Management
Rename
Unassign
Assign / Replace
Audit Trail
Record Manual Event
Drawings / Notes...
Help…
