DESCRIPTION OF HART INTERFACE
9
129
OPTISONIC 3400
www.krohne.com 11/2013 - 4002037702 - HB OPTISONIC 3400 -en-R02
9.11.4 HART Menu Tree FDM - Device Configuration
FDM supports the following standard EDDL menus:
• Root Menu
• Process Variables Root Menu (details on page 130)
• Diagnostic Root Menu (details on page 133)
• Device Root Menu (details on page 135)
In the signal converter HART DD the Root Menu it is implemented as a combination of the other
standard EDDL menus.
The menus are located in the FDM user interface as follows:
Device Configuration Window
9.11.5 Description of used abbreviations
•
Opt
Optional, depending on device implementation/configuration
•
Rd
Read only
• Loc Local DD, affects only DD views
• Cust Custody lock protection
Entry Points Entry Points Entry Points Entry Points
Device Functions Device Functions Device Functions Device Functions
Online (Root Menu)
Device (Device Root Menu)
Process Variables (Process Variables
Root Menu)
Diagnostic (Diagnostic Root Menu)
Method List
FDM Status
FDM Device Properties
FDM Tasks FDM Tasks FDM Tasks FDM Tasks
...
