80
(K1A1 + K2A2 + K3A3 + K4A4) x K5
K5 x (K1A1 + K2A2) / (K3A3 + K4A4)
Primary Wavelength allows the user to select which of the (up to) four wavelengths selected is to be
used as the primary wavelength in the Ratio and Difference calculation.
Secondary Wavelength allows the user to select which of the (up to) four wavelengths selected is to
be used as the secondary wavelength in the Ratio and Difference calculation. It is not possible to set
the primary and secondary wavelengths to the same value.
K1 to K5 allow the user to set the required constants for the calculations.
Setting Batch iD
Select the Batch ID key and enter the batch code using the alphanumeric keypad. Touch Enter to
accept or Cancel to remain as a Default.
Selecting Printer Media
The Printer Media key toggles between Internal and External Printer options.
