Post Quantitation tools
After construction or recall of a calibration curve the Quantitation Tools can be enabled by pressing the
Tools icon on the display surround.
The function of these tools is as follows:
Information
Auto Scale On/Off
Curve Fit
Curve Fit options selection
Resolution decrease
Resolution increase
Pressing this icon displays information on the calibration curve based on the currently
selected curve fit. Constants for the curve are displayed with the correlation factors, as
applicable.
This icon turns the Auto-Scale on and off. (When set to Off manually entered values from
the settings are invoked).
Pressing this icon opens a new menu bar.
Pressing this icon cycles through the curve fit options. Exit this function by using the Back
arrow on the display surround.
Decreases the resolution of the concentration display – 0.001, 0.01, 0.1, 0.
Increases the resolution of the concentration display – 0, 0.1, 0.01, 0.001.
