74
(K1A1 + K2A2 + K3A3 + K4A4) x K5
K5 x (K1A1 + K2A2) / (K3A3 + K4A4)
Primary Wavelength allows the user to select which of the (up to) four wavelengths selected is used
as the primary wavelength in the Ratio and Difference calculation.
Secondary Wavelength allows the user to select which of the (up to) four wavelengths selected is
used as the secondary wavelength in the Ratio and Difference calculation. It is not possible to set the
primary and secondary wavelengths to the same value.
K1 to K5 allow the user to set the required constants for the calculations.
Setting Batch iD
Select the
Batch ID key and enter the batch code using the alphanumeric keypad. Select Enter to
accept or
Cancel to remain as a default.
Selecting Printer Media
The
Printer Media key toggles between Internal and External Printer options.
