Jenway 6715 User Manual
Page 90
72
Selecting Measurement Mode
The
Measurement Mode key toggles between Absorbance and Transmittance.
Selecting Sample Style
This option allows the user to select to measure one sample at up to four wavelengths, or to measure
up to four samples at different wavelengths when the 8-position cell holder is fitted.
Single – allows a single sample to be measured at up to 4 wavelengths.
Multiple – allows up to 4 samples to be measured at single different wavelengths.
This parameter is used in conjunction with setting wavelengths; i.e. in multiple option Sample 1 =
Wavelength 1, Sample 2 = Wavelength 2, etc, with Position 0 reserved for a common blank.
Setting Method Security
This option is only applicable to logged in users.
