Jenway 6715 User Manual
Page 66
48
Selecting Plot interval
Selecting the
Plot Interval key allows the user to toggle between 1.0nm, 5.0nm, 0.1nm and 0.5nm.
Using the
Back key to escape settings will display:
If
Yes is selected all set information will be lost and
the instrument will return to the main measurement
screen. If
No is selected the instrument returns the
Settings screen as shown.
To accept the entered information at any time, select the
Enter key to confirm. The instrument will
show the main measurement screen with the updated information.
To view the set parameters touch the status bar once and a drop down menu will appear. Touching
this bar again will return it to its original status.
6715 CVS
Continue? , if so you will lose
any changes you have made.
Yes
Cancel
