Common Utility Settings
The Common Utility settings are system-wide settings that apply to
both MANU tests and AUTO tests.
The Common Utility menu includes the following settings:
LCD settings → from page 98.
Buzzer Settings → from page 99.
Interface Settings → from page 100.
Control settings → from page 102.
LCD Settings
Description
The LCD settings include contrast and
brightness controls.
Steps
1. Ensure the tester is in VIEW status.
