GPT-9000/9000A Series User Manual

54

Note

The ARC setting range is directly related to the HI
SET current limit.

ACW: GPT-98XX

HI SET Limit

ARC Range

0.001mA~0.999mA

1.000mA ~2.000mA

01.00mA~09.99mA

01.00mA ~20.00mA

010.0mA~042.0mA

001.0mA ~080.0mA

ACW: GPT-99XX/99XXA

HI SET Limit

ARC Range

0.001mA~1.100mA

2.000mA

01.11mA~11.00mA

02.00mA ~20.00mA

011.1mA~110.0mA

002.0mA ~200.0mA

DCW: GPT-98XX

HI SET Limit

ARC Range

0.001mA~0.999mA

1.000mA ~2.000mA

01.00mA~09.99mA

01.00mA ~20.00mA

010.0mA~011.0mA

001.0mA ~020.0mA

DCW: GPT-99XX/99XXA

HI SET Limit

ARC Range

0.001mA~1.100mA

2.000mA

01.11mA~11.00mA

02.00mA ~20.00mA

011.1mA~021.0mA

002.0mA ~040.0mA
