background image

GPT-9000/9000A Series User Manual

166

GPT-9000/9000A Specifications

The specifications apply when the GPT-9000/9000A is powered on
for at least 30 minutes at 15˚C~35˚C.

Specifications


Environment
Range

Temperature

Humidity

Warranty

15˚C ~ 35˚C

≤70% (No
condensation)

Operation

0˚C ~ 40˚C

≤70% (No
condensation)

Storage

-10˚C ~ 70˚C

≤85% (No
condensation)

Installation Location

Indoors at an amplitude of up to 2000m.


AC Withstanding Voltage
Output Voltage Range

0.100kV~ 5.000kV

Output Voltage Resolution

2V

Output Voltage Accuracy

(1% of setting +5V) with no load

Maximum Rated Load(Table1) 200 VA (5kV/40mA) [GPT-98XX]

500 VA (5kV/100mA) [GPT-99XX/99XXA]

Maximum Rated Current

40mA [GPT-98XX], 100mA [GPT-99XX/99XXA]
0.001mA ~ 10mA(0.1kV≤V≤0.5kV)
0.001mA ~ 40mA(0.5kV0.001mA ~ 100mA(0.5kV99XXA]

Output Voltage Waveform

Sine wave

Frequency

50 Hz / 60 Hz

Voltage Regulation

1% +5V

[Maximum rated load → no load]

Voltmeter Accuracy

(1% of reading+ 5V)

Current Measurement Range 0.001mA~040.0mA [GPT-98XX]

0.001mA~100.0mA [GPT-99XX/GPT-99XXA]

Continued…
