GPT-9000/9000A Series User Manual
10
GPT-9000/9000A Series Overview
Series lineup
The GPT-9000/9000A Series Safety Testers are AC/DC
withstanding voltage, insulation resistance and ground bond safety
testers.
The GPT-9801/9901A are AC withstanding voltage testers, the
GPT-9802/9902A are AC/DC withstanding voltage testers and the
GPT-9803/9903/9903A are AC/DC withstanding voltage and
insulation resistance testers. The GPT-9804 & GPT-9904 include all
the test functions of the other models as well as ground bond
testing. All models can operate at up to 5kVAC for AC
withstanding voltage testing and at up to 6kVDC for DC
withstanding voltage testing (excluding the GPT-9801/9901A).
For the GPT-99XX/99XXA models, the testing terminals are also
mirrored on the rear panel for added safety and for more
permanent safety testing environments. They also include an
innovative sweep function to view test results as a graph.
The GPT-9000/9000A Series can store up to 100 manual tests, as
well as run up to 16 manual tests sequentially as an automatic test,
allowing the safety testers to accommodate any number of safety
standards, including IEC, EN, UL, CSA, GB, JIS and others.
Note: Throughout this user manual, the terms ACW, DCW, IR and
GB refer to AC Withstanding, DC Withstanding, Insulation
Resistance and Ground Bond testing, respectively. GPT-9000 refers
to any of the GPT-98XX or GPT-99XX models, GPT-9000A refers to
any of the GPT-99XXA models.
