Hired-Hand Unitized Mega Cool: Square Bottom - Manual (Page 59)

Part No. 4801-5396 Rev 5-08 Unitized System – Square Reservoir Page 59 of 63
6” Pad System Part No. Fitting Description Part No.
Square Bottom Reservoir 6418-0101 Ball valve 1-1/2" 1009-0101
Splices 0406-8088 Ball valve 1" 1009-0103
End Cap – Water Tank Version 0406-8092 Elbow 90 1-1/2" 1021-0106
End Cap Outlet – End Pump Version 0406-10079 Male Adapter 1-1/2" 1021-0109
End Cap Inlet – End Pump Version 0406-10078 Union 1-1/2" 1021-6023
Pad Supports 0406-8087 Coupling 1 1/2" 1021-0109
Float Valve 1009-0102 Body Tank Adaptor 1021-6021
Float Pivot Extension Arm 1009-0112 Coupling 1-1/2" to 1-1/4" 1021-6016
Float 90° Swivel 1009-0109 1” Tank Adaptor 1021-6019
Float Bracket End 0404-4973 3/4” Fitting 1021-0129
Float Bracket Adjustment End 0404-4974
Float Ball 1009-0111
In-Line Pump (60 Hz) 1062-5027
In-Line Pump (50 Hz) 1062-5013
Splash Guard 0403-4548
Kit Description Part No.
Splash Guard Splice 0403-4557 Kit Brush Cleanout IC/MC 6650-5400
Splash Guard Support Bracket 0403-4547
In-Line Filter 1049-0100
Filter Screen 1049-0101
6" Thick Cooling Pads Part No.
Filter Gasket 1049-0102 4’ tall 30/30 flute angel w/o coating 0050-7505
Tank Gasket 1028-5003 5’ tall 30/30 flute angel w/o coating 0050-7503
Water Tank Cover 0406-8197 6’ tall 30/30 flute angel w/o coating 0050-7504
Water Tank 0406-8196 4’ tall 45/15 flute angel w/o coating 0050-7660
Drip Rail Cover 0403-10364 5’ tall 45/15 flute angel w/o coating 0050-7661
6’ tall 45/15 flute angel w/o coating 0050-7662
4’ tall 45/15 flute angel w coating 0050-7601
Lock Motor Description Part No.
5’ tall 45/15 flute angel w coating 0050-7600
GEAR Lock 600Nm 230v 1P 3017-5411 6’ tall 45/15 flute angel w coating 0050-7602
GEAR Lock 600Nm 230/480v 3P 3017-5409
Lock Motor Kit 6450-7567
Mega-Cool Replacement Parts
